Custom programs on the Minelab Equinox let you clone base modes like Park 1 or Field 2, then fine-tune recovery speed and discrimination for your specific targets and ground conditions. Your Equinox 800 and 900 store up to 8 custom programs, while the 600 and 700 also support user-saved configurations. Changes auto-save to your active user profile, so you’re never starting from scratch. Keep going to master every setting that separates good finds from great ones.
Key Takeaways
- Perform a factory reset by long-pressing the power button until “FP” appears before creating custom programs to ensure a clean baseline.
- Clone a base detection mode like Park 1 or Field 2, then adjust recovery speed and discrimination settings to create custom programs.
- Changes to settings auto-save to the active user profile, confirmed by the user profile icon in the upper-right corner of the display.
- The Equinox 800 and 900 support up to 8 custom programs, including exclusive Gold mode for prospecting with maximized sensitivity settings.
- Assign frequently used configurations to specific modes for quick field access, reducing adjustment time and improving overall detection efficiency.
What Are Custom Programs on the Minelab Equinox?
Custom programs on the Minelab Equinox are user-saved configurations that let you store tailored detection settings within the detector’s built-in modes. Instead of resetting preferences each hunt, you clone a base mode—like Park 1 or Field 2—then adjust recovery speed, discrimination, and other parameters to match your specific conditions. Those changes auto-save directly to your user profile.
Custom program benefits are substantial: you eliminate repetitive setup, maintain consistency across hunts, and respond faster to changing terrain.
The Equinox 800 and 900 store up to eight custom programs, giving you flexible, mode-specific configurations ready on demand.
Equinox user experiences consistently confirm that custom programs reduce setup time and sharpen target identification, putting you in full control of your detection strategy from the moment you power on.
Check Which Equinox Models Support Custom Programs
Before committing to a custom program strategy, you’ll need to confirm your Equinox model actually supports the feature.
This Equinox model comparison clarifies exactly where custom program benefits apply:
- Equinox 600 – Supports Park, Field, and Beach modes with custom programs
- Equinox 700 – Mirrors 600 capabilities with full custom program access
- Equinox 800 – Grants access to Gold mode plus exclusive features, expanding your customization freedom
- Equinox 900 – Delivers the complete detection suite, including Gold mode and full program storage
- 800/900 Exclusive – Only these models store up to 8 custom programs across multiple modes
Knowing your model prevents wasted setup time.
If you’re running an 800 or 900, you’re operating with maximum flexibility. Lower models still support profiles but with reduced multi-program storage capacity.
Factory Reset Your Equinox Before Building Custom Programs
Starting with a clean slate matters more than most detectorists realize—a factory reset clears any residual settings that could interfere with your new custom programs.
Understanding factory reset importance means you’re protecting every custom configuration you build afterward.
To execute the reset, long-press the power button while the unit’s off until “FP” appears on the display. Your Equinox immediately reverts to default factory settings, giving you a verified baseline.
Page 60 in your user guide documents this procedure precisely.
Once reset, you’re ready to leverage cloning benefits by copying a base mode—like Park 1—directly into your user profile.
Cloning from a clean factory state eliminates conflicting variables, ensuring your saved programs behave exactly as you’ve designed them during every hunt.
Clone a Detection Mode to Start Your First Custom Program
Once your Equinox is factory reset, you’re ready to clone a base detection mode into your user profile—the essential first step in building a functional custom program.
Understanding custom mode advantages starts here: cloning preserves factory settings while giving you full control to modify them freely.
Cloning a factory mode keeps your baseline intact while unlocking total freedom to customize settings your way.
Cloning tips to maximize your detecting freedom:
- Select Park 1 for coin-hunting in trashy, target-rich environments
- Choose Field 2 when hunting open farmland for deeper, larger objects
- Clone Beach mode before heading to saltwater or wet sand
- Store up to 8 custom programs across different detection modes
- Always clone before adjusting—never modify factory settings directly
Short-press the user profile icon after cloning to confirm your program is active and ready for customization.
Dial In Recovery Speed and Discrimination Before You Save
With your cloned program active, two settings demand your attention before saving: recovery speed and discrimination.
Recovery speed controls how quickly the detector separates targets in trashy ground. Crank it too high and you’ll miss deep targets; set it too low and iron masking becomes a problem. Test different values in your actual hunting conditions before committing.
Next, tighten your discrimination scale. Notch out iron and foil ranges you’re confident rejecting, but avoid over-discriminating—you’ll cut desirable targets that share similar ID numbers.
Each adjustment you make automatically saves to your active user profile, so there’s no separate save step required.
Dial both settings deliberately based on ground conditions, not guesswork. Once they’re optimized, your custom program is genuinely ready for the field.
Save Your Custom Program to the User Profile
Locking your custom program into the user profile requires one prior step: a factory reset. Long-press the power button until “FP” displays, clearing the slate for clean program management.
Then execute this sequence:
- Clone your chosen base mode—Park 1, Field 2, or Beach—directly into the user profile.
- Adjust your dialed-in settings; they auto-save instantly.
- Confirm the user profile icon appears in the upper-right corner.
- Short-press the user profile icon to toggle between custom and factory modes freely.
- Store up to 8 custom programs across different modes on the 800 and 900.
Your user profiles now carry your exact preferences, hunt after hunt, without rebuilding from scratch each time.
Save Up to 8 Custom Programs on the Equinox 800 and 900
Eight custom programs fit inside the Equinox 800 and 900, giving you dedicated storage for every mode you run. Each detection mode — Park, Field, Beach, and Gold — supports its own custom settings, letting you tailor user preferences independently across mode variations.
To build your library, clone a base mode into a user profile slot, adjust your target parameters, and save. Repeat this process for Field 2, Beach 1, Gold mode, and beyond.
A few program tips keep this efficient: always factory reset before cloning a new base, and confirm your user profile icon appears after saving.
You’re not locked into one configuration. With eight slots available, you control exactly how the detector performs across every environment you hunt.
Best Custom Program Settings for Coins, Jewelry, and Gold
Dialing in the right custom program for coins, jewelry, or gold starts with understanding how recovery speed and ID discrimination interact. Each target type demands different recovery settings to maximize your finds.
The right custom program begins where recovery speed and ID discrimination meet — and every target type demands something different.
- Coin hunting: Clone Park 1, lower recovery speed for deeper targets in trashy soil
- Jewelry detection: Clone Park 2, raise recovery speed to isolate fine rings from iron trash
- Gold prospecting: Use Gold mode (800/900), maximize sensitivity and tighten discrimination
- Mixed-target sites: Clone Field 2, balance recovery settings for varied depths
- Beach hunting: Clone Beach mode, adjust ID discrimination to filter saltwater interference
Save each configuration as a separate custom program so you’re never locked into someone else’s defaults.
Switch Between Custom Programs Quickly in the Field
Once you’ve saved your custom programs for coins, jewelry, and gold, getting to them fast in the field is what separates a productive hunt from a frustrating one.
Your field adaptability depends entirely on how efficiently you’ve structured your stored programs. On the Equinox 800 and 900, you can store up to 8 custom programs across detection modes.
Use the user profile button to toggle between your cloned configurations instantly. Short-press the icon to switch from factory defaults to your saved settings without traversing deep menus.
Program efficiency improves when you assign your most-used configurations to frequently accessed modes like Park 1 or Field 2.
Know your layout before you hunt so every switch feels instinctive, keeping your focus on the ground, not the controls.
Frequently Asked Questions
You can’t freely share custom programs across all units due to model differences—program compatibility depends on features like Gold mode, exclusive to the 800 and 900, so always verify your target model’s capabilities first.
Do Custom Programs Survive a Firmware Update on the Equinox?
Like a ship weathering a storm, your custom programs may not always survive a firmware update. Always back up settings beforehand, as firmware stability can’t guarantee program compatibility across every Equinox update cycle.
Will a Dead Battery Erase Saved Custom Programs on the Equinox?
Your custom programs won’t erase when the battery dies—the Equinox’s non-volatile memory guarantees solid program retention regardless of battery life. Your saved settings stay intact, so you’re free to detect without worrying about losing configurations.
Can Custom Programs Be Exported or Backed up to a Computer?
Want full control over your custom program management? Unfortunately, you can’t export or back up programs to a computer due to software compatibility limitations — your Equinox stores all eight custom programs internally, so protect them carefully.
Does Waterproofing Affect Custom Program Functionality in Wet Conditions?
Waterproofing doesn’t affect your custom programs’ functionality. You’ll maintain full wet detection capability across all saved profiles. Your Equinox’s waterproof performance guarantees settings operate identically whether you’re detecting in dry fields or submerged beach conditions.
