Start by assembling your Land Ranger Pro‘s five main components and installing two 9-volt alkaline batteries. Familiarize yourself with the LCD display showing Target ID (0-99) and depth indicators. Power on and select one of seven preset modes using the PRESET button. Perform ground balance in All Metal mode by pressing GroundTrac while sweeping the coil 10-15cm above ground until 2-4 bars display. Adjust discrimination settings with DISC TARGET and use the pinpoint button for precise target location. The following guide covers advanced customization and troubleshooting techniques.
Key Takeaways
- Assemble five main components: S-rod, armrest, upper rod, lower stem, and 11-inch coil with included hardware and fasteners.
- Install two 9-volt alkaline batteries, then use PRESET button to cycle through seven detection modes for different hunting environments.
- Perform ground balance in All Metal mode by pressing GroundTrac button while sweeping coil until 2-4 LCD bars display.
- Use 4-tone audio system and Target ID numbers (1-99) to identify metals; high tones indicate valuable copper, silver, or bronze.
- Customize discrimination settings with DISC TARGET pad and Notch button to eliminate unwanted targets like iron or foil.
Unboxing and Initial Assembly
When you open the Bounty Hunter Land Ranger Pro box, you’ll find five main components: the S-rod with attached control housing, arm rest, and locking collar; the upper rod and lower stem; an 11-inch double D search coil; hardware consisting of a bolt, knurled knob, and two washers; plus an owner’s manual and digging tool coupon.
Your unboxing experience reveals a well-organized detector ready for field deployment. The control box features two mounting screws, a battery compartment for two 9V batteries, a 1/4-inch headphone jack, speaker port, vented side speaker, padded foam grip, and arm cuff.
For successful assembly tips, verify all components before starting. Check the control housing’s connectivity points and confirm the locking collar rotates freely.
Inspect the coil cable for proper slack and examine hardware pieces for secure fitting capability. The foam grip handle ensures comfort during extended detecting sessions. The detector is designed as a lightweight unit at 2.5 pounds for comfortable handling during extended use.
Understanding the Control Panel and Display
The control panel serves as your command center, featuring buttons that access multiple modes and adjust key parameters like sensitivity and discrimination.
The LCD display presents critical information through a two-digit Target ID system (0-99), depth indicators, ground balance status, and tone mode selections. The machine includes VRE tone breaks that allow you to customize low and high tone thresholds for improved target identification.
You’ll need to understand each icon and button function to maximize the detector’s performance across its seven preset modes and customizable settings. The 11-inch Double-D waterproof coil provides excellent ground coverage while remaining fully submersible for detecting in shallow water.
LCD Display Icons Explained
Understanding your Land Ranger Pro’s LCD display requires familiarity with five key icon categories that provide real-time detection data.
Target ID Icons show graphic symbols for iron, foil, pull tabs, nickels, pennies, dimes, and quarters. The arrow points to your detected target’s probable identity.
Color-coded bands separate ferrous from non-ferrous metals—copper-iron for junk, goldish-yellow for valuable aluminum and nickel range, silver for clad coins.
Numeric Target ID displays conductivity from 1-99 across 43 segments, giving you precise lcd display functionality before digging. Higher numbers indicate greater conductivity.
Discrimination Indicators provide icon meaning clarity through gray shading on rejected iron, crosses below unwanted targets, and disappearing ranges based on your settings.
Depth Indicators show five segments calibrated for coin-sized objects up to 10 inches. The two-digit target indicator works alongside the depth gauge to help you assess whether detected objects warrant excavation.
Status Icons monitor battery life, sensitivity, volume, and tone selection. The large LCD display ensures clear target identification even in varying outdoor lighting conditions.
Control Button Functions Overview
Mastering your Land Ranger Pro’s control panel requires knowledge of four primary button categories that transform detection settings in real time.
Control button importance becomes clear when you’re rapidly switching between hunting environments. Press PRESET to cycle through seven detection modes—each press advances to the next configuration. DISC TARGET locks your programmed discrimination settings, while ACCEPT and REJECT buttons customize target responses.
You’ll find adjusting sensitivity essential for depth versus stability—use LOW and HIGH touchpads to select from ten power levels. Volume controls offer identical ten-level adjustment.
PINPOINT activates precise target location mode with depth indication. Ground balance buttons enable manual or automatic soil adaptation.
These controls empower you to configure detection parameters without menu diving, maximizing your hunting freedom. The detector’s large backlit LCD screen displays all your current settings and target information for easy viewing in various lighting conditions.
Powering Up and Basic Settings Configuration
Before detecting your first target, you’ll need to install a 9-volt alkaline battery in the compartment on the back of the control housing.
Slide the door open, insert your battery, and close it securely. Skip ordinary zinc carbon batteries—they’ll limit your freedom in the field. Alkaline batteries deliver 20-25 hours of operation, while rechargeable nickel metal hydride options provide 8 hours.
Choose alkaline batteries for 20-25 hours of field time—rechargeable options last only 8 hours, and zinc carbon batteries severely restrict your detecting range.
Press the power button for immediate startup at default power settings. Your detector operates at 7.69 kHz and weighs 2.4-2.5 pounds with the 11-inch coil attached. The adjustable length feature allows you to customize the detector for comfortable extended use.
Navigate the menu using power buttons to adjust speaker volume (0-10) and ground settings (0-99). Monitor battery life through the icon’s three segments, which indicate voltage levels from full charge down to the flashing outline warning. Keep a backup set of alkalines on hand to avoid interruptions during extended detecting sessions.
Selecting and Customizing Operating Modes
With your Land Ranger Pro powered on and ready, you’ll need to select the operating mode that matches your detecting goals.
Press MODE to cycle through seven preset mode customization options: Coins, Jewelry, Artifacts, 2 Tones, 3 Tones, 4 Tones, and All Metal. The first three modes operate automatically with sensitivity adjustments (1-10) and volume control only.
Modes four through seven enable manual customization—discrimination, V-Break, and Notch settings. All Metal mode rejects nothing and excels in low-trash environments. Each mode calibrates parameters for specific targets and conditions.
Press MENU to access adjustable options, using +/− buttons for changes. Hold sensitivity buttons for quick max/min settings. The detector displays a 99-segment Target-ID system to help you identify detected objects. Your detector saves these preferences, giving you turn-on-and-go convenience or complete customization freedom.
Performing Ground Balance Calibration
Ground balance calibration neutralizes your detector’s response to soil minerals, preventing false signals that mask genuine targets.
You’ll perform this procedure in All Metal mode, where it’ll carry over to modes 2, 3, and 4. Modes C, J, and A stay preset at 82 without manual adjustment.
Master these ground balance techniques: Press the GroundTrac button while sweeping your coil horizontally 10-15cm above the ground.
Watch the fan-shaped LCD bars adjust—repeat until 2-4 bars remain displayed. This manual adjustment compensates for mineralized conditions that’d otherwise limit your hunting freedom.
The factory preset works adequately, but customizing for your specific terrain maximizes depth and eliminates iron mineral interference.
You’ll experience superior performance in challenging soils and saltwater environments, plus faster target location compared to tracking methods.
Audio Tone Identification and Adjustment
Once you’ve fine-tuned your ground balance, you’ll rely on the Land Ranger Pro’s 4-tone audio identification system to distinguish metal types without digging every signal.
The audio feedback significance becomes clear as copper, silver, and bronze produce high tones, while iron triggers low responses.
You’ll master tone customization techniques through the V-Break feature—set your preferred breakpoint (like 42) so targets at or below produce low tones, giving you discrimination control.
The V.C.O. method increases both pitch and volume as signal strength rises, revealing target depth and size characteristics.
Adjust speaker volume from 0-10 for peak detection. Set your ALL METAL mode audio level so the threshold hum remains barely audible—this guarantees you won’t miss faint signals from valuable targets.
Target Detection and Pinpoint Techniques
When you detect a target in motion mode, observe the Target-ID number on the LCD display—values from 1 to 99 indicate conductivity level, with higher numbers representing more conductive metals like coins.
If the reading jumps erratically (for example, alternating between 76, 35, and 62), you’ve likely found a non-round object or deeply buried coin that requires verification.
Once you’ve identified a promising target, press and hold the pinpoint button, position the searchcoil slightly off the ground to the side of the target, then move it slowly across the area until you hear the loudest signal—this marks the target’s center for precise recovery.
Reading Target-ID Signals
The Land Ranger Pro’s target identification system combines three detection methods—visual arrow indicators, numerical conductivity values, and audio tones—to help you determine what’s buried before you dig.
Your target identification techniques start with the LCD arrow pointing to categories like IRON/FOIL, PULL TAB, or precious metals. The two-digit numerical ID (0-99) measures conductivity—higher numbers mean higher-value targets.
Audio tones provide instant feedback: low grunts indicate iron, while high clear tones signal silver-like conductivity.
For effective signal interpretation strategies:
- Sweep slowly from multiple angles to verify consistent Target ID readings
- Monitor both numerical values and audio tones simultaneously for confirmation
- Adjust sensitivity between 0-10 based on soil conditions and interference levels
Remember that depth, mineralization, and target orientation affect accuracy.
Repeatable, crisp signals across different sweep angles confirm legitimate targets worth recovering.
Using Pinpoint Mode
After you’ve identified a promising target through the Land Ranger Pro’s discrimination mode, you’ll activate pinpoint mode by pressing and holding the dedicated pinpoint button on your control box. This narrows down your target’s location with pinpoint accuracy.
Position your coil over the signal—you’ll hear the tone intensify as you approach the target’s center. The 11″ DD coil’s center dot marks your hot spot.
For advanced techniques, sweep perpendicular to your initial detection line, marking where the sound peaks. Rotate 90 degrees and resweep across that marked line. The intersection reveals your dig spot.
Remember: louder tones indicate shallower targets. You can also hold the mode button during your swing for temporary AM mode, which helps identify deeper, uncertain targets more reliably.
Discrimination and Notch Settings
Discrimination settings allow you to filter out unwanted metals and focus on valuable targets with your Land Ranger Pro.
You’ll access these discrimination techniques through the DISC TARGET touch pad, where preset modes automatically reject iron, foil, and pull tabs. The Disc Level ranges from 0-59, eliminating any target IDs at or below your selected value.
Master these notch settings for ideal performance:
- Press the large Notch button to accept or reject entire target categories displayed along the Target Category Arc
- Set V-Break values to customize audio responses, creating low tones for IDs below your threshold
- Utilize Progressive Iron Discrimination with four levels to eliminate various iron sizes before fine-tuning
Maintenance and Troubleshooting Tips
Proper maintenance keeps your Land Ranger Pro performing at peak efficiency for years of reliable treasure hunting.
For battery care, use only 9-volt alkaline batteries—avoid heavy duty or zinc carbon types. You’ll get 20-25 hours per set. When the low indicator appears, push down firmly on the battery bottom to replace it. Access the compartment by sliding the door on your control housing’s back.
For coil maintenance, align the cable plug’s pins with connector holes, then twist the locking collar clockwise until secure. Leave slack at the bottom so your searchcoil pivots freely.
If you’re experiencing constant signals, reduce sensitivity or lower the threshold. Press Ground Grab periodically to minimize drift in changing conditions. Reset to factory defaults by holding Mode + Power simultaneously.
Frequently Asked Questions
What Is the Maximum Depth for Detecting Gold Rings Versus Silver Coins?
Imagine finding buried treasure—you’ll detect silver coins at 7-10 inches deep thanks to superior silver coin sensitivity, while gold ring detection maxes out shallower due to lower conductivity. Adjust your sensitivity settings higher for maximum freedom hunting both targets effectively.
Can the Detector Be Fully Submerged or Only the Search Coil?
Only the search coil and lower rod section can be submerged—not the entire detector. The waterproof features don’t extend to the control box, so you’ll need to keep the housing dry while detecting in shallow water environments.
How Does Temperature Affect Battery Life and Detector Performance in Cold Weather?
Cold weather greatly reduces battery efficiency below 32°F, slowing chemical reactions and draining power faster. You’ll need lithium batteries instead of alkaline ones, keep spares warm in inner pockets, and attach hand warmers to your control box.
What Headphones Are Compatible With the Quarter-Inch Jack on This Detector?
Like finding treasure without limits, you’ll discover any quarter-inch wired headphone types work perfectly—official Bounty Hunter models, Garrett, Minelab, or Nokta options all deliver excellent audio quality. Choose what suits your detecting style best.
Does the 5-Year Warranty Cover the Search Coil and Control Housing Damage?
The 5-year warranty coverage protects against manufacturing defects, not accidental coil damage or control housing impacts. You’re covered for workmanship flaws only. Contact the manufacturer directly to confirm specific component claims before assuming you’re protected.
