You’ll find the YSI EXO2 Multiparameter Sonde leads with seven sensor ports and 90-day battery life, while the Renke RS-ZD Turbidity Sensor excels at sediment monitoring with its fiber optic design. The Yosemite Y521-A Conductivity Sensor delivers ±1ppt salinity accuracy through four-electrode architecture, and the Seametrics PT12 tracks depth changes with ±0.25% precision. For algae blooms, Yosemite’s fluorescence-based sensor detects down to 1 cell/mL. Each detector addresses specific monitoring challenges, and understanding their technical specifications helps you select the best configuration for your watershed conditions.
Key Takeaways
- YSI EXO2 offers seven sensor ports and 90-day battery life, ideal for comprehensive multi-parameter monitoring in rivers up to 250m deep.
- Renke RS-ZD measures turbidity with fiber optic technology, providing sediment transport data for erosion studies with minimal power consumption.
- Yosemite Y521-A detects contamination and nutrient pollution using four-electrode conductivity measurement with ±1ppt salinity accuracy.
- Seametrics PT12 converts water pressure to depth data with ±0.25% accuracy, supporting both SDI-12 and Modbus communication protocols.
- Yosemite Blue-Green Algae Sensor identifies harmful cyanobacteria blooms down to 1 cell/mL using fluorescence-based detection technology.
YSI EXO2 Multiparameter Sonde for Comprehensive Water Quality Monitoring
Deployment efficiency peaks with 90-day battery life at 15-minute logging intervals, storing over 1,000,000 readings in 512 MB memory.
The central antifouling wiper rotates automatically each logging cycle, keeping optical sensors clean without chemicals.
Titanium construction and welded housings guarantee reliability in harsh field conditions where equipment failure isn’t an option.
The sonde operates at depths from 0 to 250m, making it suitable for both shallow creek monitoring and deep river measurements.
Seven universal sensor ports enable simultaneous monitoring of multiple parameters including conductivity, dissolved oxygen, pH, turbidity, and algae measurements.
Renke RS-ZD Turbidity Sensor for Suspended Solids Detection
The IP68-rated probe withstands submersion to 20 meters and handles 0.6MPa pressure, letting you deploy it in demanding field conditions without backup equipment.
Its fiber optic structure blocks ambient light interference while the corrosion-treated surface guarantees 2+ years of continuous operation.
Factory calibration eliminates tedious field adjustments—you’ll install and start collecting turbidity measurement data immediately.
The 0.2W power consumption supports remote installations where suspended solids tracking matters most: sediment transport studies, wastewater compliance, and erosion monitoring.
The built-in temperature transmitter provides automatic compensation to maintain measurement accuracy across varying water conditions.
The device’s network security measures activate upon detecting unusual data transmission patterns, protecting your monitoring system against unauthorized access.
Yosemite Y521-A Conductivity Sensor for Salinity and TDS Measurement
Four-electrode architecture separates the Yosemite Y521-A from conventional two-electrode sensors, delivering measurement precision across the 0-100mS/cm range (or 0-200mS/cm in the Y521-A3 variant).
You’ll monitor contamination events, nutrient pollution, and industrial discharge with ±1ppt salinity measurement accuracy spanning 0-80ppt (standard) or 0-175ppt (Y521-A3).
Critical specifications for independent monitoring:
- IP68-rated housing withstands submersion with nickel, PEEK, and titanium alloy construction
- Factory pre-calibration eliminates field setup—deploy immediately upon receipt
- RS-485 interface with MODBUS protocol connects to your existing data systems
- 0.2W power consumption extends battery-powered deployments in remote locations
- Simultaneous output of conductivity, salinity, TDS accuracy readings, and temperature
The sensor’s compact Φ22mm × 175.5mm dimensions minimize flow disruption while 10-meter cabling (customizable) accommodates varied installation depths. The four-electrode design prevents polarization effect during continuous operation, enabling extended deployments without recalibration maintenance. Technical support inquiries receive responses within 24 hours through multiple channels including email at sales@yosemitech.com and live chat.
Seametrics PT12 Submersible Pressure Sensor for Stream Depth Tracking
Stream gauging demands pressure sensors that convert hydrostatic measurements into reliable depth data, and the Seametrics PT12 delivers this conversion with SDI-12 v1.3 digital output that interfaces directly with environmental data loggers.
You’ll get ±0.25% FSO accuracy in a compact 0.75″ diameter housing built from 316 stainless steel or titanium, designed for sustained submersion in creek and river conditions.
Choose between absolute (non-vented) or gauged (vented) configurations depending on your pressure measurement requirements.
The PT12-BV barometric version provides reference compensation for absolute sensors, eliminating atmospheric interference in your environmental monitoring calculations.
Barometric compensation removes atmospheric pressure variables from absolute sensor readings for precise environmental data collection.
You can daisy-chain units up to 200 feet on single cable runs, reducing installation complexity.
Pressure ranges span 5 to 300 PSI, with optional USGS OSW enhanced calibration available for 15 PSIG units requiring regulatory-grade accuracy.
The sensor supports Modbus RTU communication protocol alongside SDI-12, providing flexible integration options for diverse environmental monitoring systems.
The unit employs a rugged piezo-electric pressure element that remains media isolated from the liquid environment, ensuring long-term reliability in groundwater and flow monitoring applications.
Yosemite Blue-Green Algae Sensor for Cyanobacteria Quantification
When harmful algal blooms threaten your stream monitoring program, fluorescence-based detection provides the quantification speed and accuracy you’ll need for timely intervention decisions.
The Yosemite Y513-A delivers fluorescence efficiency that eliminates manual counting delays while maintaining exceptional cyanobacteria stability measurements down to 1 cell/mL resolution.
You’ll appreciate the operational independence this sensor provides:
- 0-300,000 cells/mL range (expandable to 2,000,000) with R² > 0.999 linearity
- Self-cleaning brush prevents biofilm interference without your intervention
- IP68-rated titanium housing withstands 30-meter depths and 0-50℃ conditions
- RS-485 MODBUS output integrates seamlessly with existing monitoring infrastructure
- Direct deployment capability—no sample preprocessing required
The integrated calibration storage enables autonomous field installation, while mechanical cleaning extends maintenance intervals considerably beyond static sensor designs.
The sensor’s 0.2W power consumption makes it suitable for solar-powered remote installations where energy efficiency is critical.
For product specifications or pricing details, you can contact Yosemite Technologies directly and expect a response within 24 hours.
Frequently Asked Questions
How Do I Choose Between Pole-Mounted and Floating Deployment Systems for Rivers?
Choose pole-mounted advantages for fixed-position accuracy in straight channels with stable bathymetric mapping. Select floating deployment benefits when you’re tracking drifting debris in dynamic currents, though you’ll face 1.1km detection limits and repositioning challenges.
What Maintenance Schedule Is Recommended for Anti-Fouling Wipers in Creek Monitoring?
Fouling can wreck your data collection fast. You’ll want bi-weekly to monthly wiper maintenance intervals for creek monitoring, adjusting based on seasonal conditions. Smart fouling prevention means inspecting brush splay regularly and letting telemetered data guide your schedule.
Can These Sensors Withstand Flash Floods and High Turbulence in Creeks?
You’ll find excellent flood resilience with IP67-rated sensors like XL-MaxSonar and INCYT, which handle extreme conditions. For superior turbulence detection, SonTek’s acoustic Doppler technology actively measures velocity profiles, making them ideal for unpredictable flash flood scenarios.
How Does Cellular Telemetry Compare to Satellite for Remote Stream Locations?
You’ll find cellular coverage fails in backcountry streams, making satellite your go-to despite higher satellite latency. Cellular wins on cost and speed where towers exist, but satellite delivers true independence for off-grid creek monitoring anywhere.
What Calibration Frequency Ensures Accuracy in Dynamic River Conditions?
You’ll need daily dissolved oxygen checks and weekly pH/conductivity dynamic calibration in challenging river conditions. Bi-weekly full sensor validation works for stable streams, but don’t hesitate to recalibrate whenever you suspect drift—your data integrity depends on it.
